Introduction
The Battery Health Monitoring System (BHMS) is an intelligent and advanced solution designed for real- time remote monitoring of battery condition and performance. It enhances operational safety, ensures optimal battery efficiency, and provides actionable insights for proactive maintenance and extended battery life. It significantly extends battery life and improves overall system efficiency. The system plays a vital role in environments where uninterrupted battery performance is crucial, including applications in telecom, railways, UPS systems, and energy storage solutions.
What BHMS Monitors?
- Bank & Individual Cell Voltage
- Charging & discharging Current
- Coulomb Counter
- Battery Bank Temperature
- Temperature of cell
Software Features
- Monitor the real-time data values remotely.
- Check the alert insights and warnings \
- Get instant overview of all Battery Banks at a glance.
- Check and print the history records of particular date and time.
- Plan advance maintenance scheme based on alerts.
Technical Specification
| Parameters | Descriptions |
|---|---|
| Rated Voltage | 48 V DC |
| Operating Voltage Range | 30 – 60 V DC |
| Nominal Input Current | 200 mA @ 48 V DC |
| Operating Temperature | 0°C to 85°C |
| Processor | ARM-based Microcontroller |
| Charge Measurement | Coulomb Counting (Charge IN & OUT Calculation) |
| Event Storage Capacity | 5,00,000 Events |
| Networking Capability | Wired / Wireless Networking of BHMS Modules |
| Number of Channels | 24 |
| Measurement Accuracy | ±0.10% |
