Introduction
JMV's ruggedized Dome and Wedge IP Cameras are purpose-built for railway and critical infrastructure applications, delivering high-definition video surveillance with exceptional reliability. Engineered to perform in demanding environments, these cameras provide continuous monitoring, superior image clarity, and robust durability, ensuring enhanced safety, security, and operational visibility across coaches, stations, metros, tunnels, and other critical facilities.
Key Features
- Defogger: Clear images in foggy weather.
- Multiple Video Streams: H.265/H.264 for efficient bandwidth & storage use.
- Activity-Based Recording: Saves storage and reduces unnecessary data.
- Low Light Performance: 0.05 Lux for colored images in dark conditions.
- Infrared Night Vision: Up to 30m coverage.
- Durability: IK10 vandal-proof, IP65/67 weatherproof.
- Wide Dynamic Range (120 dB): Handles high-contrast lighting
Technical Specifications
| Parameter | Dome Camera | Wedge Camera |
|---|---|---|
| Resolution | 2,4,5,8MP | 4MP |
| Frame Rate | ≥ 25 FPS | ≥ 45 FPS |
| Lens Options | Focal Length ≥2.8mm | Focal Length ≥3.6mm |
| Illumination | 0.05 Lux (Color) | Focal Length ≥3.6mm |
| Power (PoE) | ≤ 10W | ≤ 10W |
| Operating Temp | –25°C to +70°C | –25°C to +70°C |
| Protection | IP65/67, IK10 | IP65/67, IK10 |
| MTBF | ≥ 100,000 hours @40 C | ≥ 100,000 hours @40 C |
| Infrared Range | ≥ 30m | ≥ 30m |
